| APPLICABLE STANDARD | : | IS 694:2010 |
|---|---|---|
| CONDUCTOR | : | THE CONDUCTORS DRAWN FROM 99.97 % BRIGHT ELECTROLYTIC GRADE COPPER WITH MORE THAN 100% CONDUCTIVITY ARE ANNEALED AND BUNCHED TOGETHER |
| TYPE INSULATION HRFR PVC COMPOUND | : | THE BUNCH CONDUCTORS ARE INSULATED WITH SPECIALLY FORMULATED HEAT RESISTANCE FLAME RETARDANT PVC COMPOUND WITH A HIGH INSULATION RESISTANCE VALUE. THE INSULATION PROCESS IS CARRIED OUT ON MODERN HIGH SPEED EXTRUSION LINES, WHICH ENSURES HIGH ACCURACY AND CONSISTENCY IN PERFORMANCE |
| FRLS COMPOUND | : | THE BUNCH CONDUCTORS ARE INSULATED WITH SPECIALLY FORMULATED FLAME RETARDANT LOW SMOKE COMPOUND. DURING A FIRE SITUATION, THE FR-LSH COMPOUND RESTRICTS THE SPREAD OF FLAME. THE SMOKE EMISSION IS ALSO MINIMAL |
| ZHFR COMPOUND | : | THE BUNCH CONDUCTORS ARE INSULATED WITH SPECIALLY FORMULATED GRADE OF HALOGEN FREE FLAME RETARDANT (HFFR) COMPOUND IS USED. THE INSULATION DOES NOT MELT OR DROP IN CASE OF FIRE. THE SMOKE EMITTED IS TRANSPARENT, NON-TOXIC AND MINIMAL |
| OPERATING TEMPERATURE RANGE | : | TEMP -15°C TO MAX. +70°C |
| COLOUR | : | RED, YELLOW, BLUE, BLACK, GREEN, GRAY (AND ALSO OTHER COLOUR REQUEST ON CUSTOMER) |
| PACKING: | : | COILS 90m, 100m,180m,270m BOXES, REELS |
| MARKING | : | THE CABLES ARE PRINTED WITH GENERIC MARKING" JOHNSON HRFR |
| APPLICATION | : | THIS IS A PREMIUM PRODUCT OF ELECTRICAL WIRES FROM JOHNSON". THESE CABLES ARE IDEALS FOR WIRING IN RESIDENTIAL AND COMMERCIAL COMPLEXES, HIGH-RISE BUILDING, HOTELS, HOSPITALS, SCHOOL, COLLEGES ETC. WHERE DENSITY OF PEOPLE IS HIGH. DURING A FIRE THESE CABLES NOT ONLY EMIT LESS SMOKE AND TOXIC HYDROCHLORIC ACID GAS BUT ALSO RETARD THE SPREAD OF FIRE ENABLING THOSE TRAPPED INSIDE TO ESCAPE SAFELY |
| FEATURE | : | MANUFACTURED FROM BRIGHT ANNEALED 99.97 % PURE COPPER CONDUCTORS THESE CABLES HAVE LOW CONDUCTOR RESISTANCE RESULTING IN POWER SAVING. -THESE WIRES ARE INSULATED WITH A SPECIAL GRADE PVC COMPOUND FORMULATED AND MANUFACTURED IN-HOUSE. -THE INSULATION IS FAR SUPERIOR IN TERMS OF CRITICAL OXYGEN AND TEMPERATURE INDEX. ALSO IN LIGHT TRANSMISSION AND ACID GAS GENERATION. -THE SKIN COLORATION OFFER HIGH INSULATION RESISTANCE AND LONG LIFE. |
| ISO CERTIFICATION | : | ISO 9001:2015, ISO 45001:2018, ISO 14001:2015, CE, RoHS |
| PRODUCT CERTIFICATION | : | IS 694:2010  IS 7098 P-1  , TUV RHEINLAND CERTIFICATE NO. R 60160877
|
| SIZE DIMENSIONS AND RATING | ||||||
|---|---|---|---|---|---|---|
| NOMINAL CROSS SECTIONAL AREA | NUMBER/ NOMINAL DIA OF WIRES* (NOM.) | NOMINAL THICKNESS OF INSULATION | APPROX OVERALL DIA (+/-0.2 mm) | MAXIMUM DC RESISTANCE OF CONDUCTOR AT 20° C | MAX. CURRENT CARRYING CAPACITY AMPS | |
| CASING | CONCEALED | |||||
| mm² | Number/mm | mm | mm | Q/km | Amps | |
| 0.5 | 16/0.2 | 0.6 | 2.10 | 39.00 | 4 | 4 |
| 0.75 | 24/0.2 | 0.6 | 2.30 | 26.00 | 7 | 6 |
| 1 | 32/0.2 | 0.6 | 2.50 | 19.50 | 12 | 11 |
| 1.5 | 30/0.25 | 0.7 | 2.80 | 13.30 | 16 | 13 |
| 2.5 | 50/0.25 | 0.8 | 3.40 | 7.98 | 22 | 18 |
| 4 | 56/0.3 | 0.8 | 4.10 | 4.95 | 29 | 24 |
| 6 | 84/0.3 | 0.8 | 5.10 | 3.30 | 37 | 31 |
| TEST DETAILS | ||||||||
|---|---|---|---|---|---|---|---|---|
| FR | FRLS | ZHFR | ||||||
| TEST | SPECIFICATION | SPECIFIED VALUE | TEST | SPECIFICATION | SPECIFIED VALUE | TEST | SPECIFICATION | SPECIFIED VALUE |
| CRITICAL OXTYGEN INDEX | ASTM-D 2863 | 29% MINIMUM | CRITICAL OXYGEN INDEX | ASTM-D2863 | 29% MINIMUM | CRITICAL OXYGEN INDEX | ASTM-D2863 | 29% MINIMUM |
| TEMPERATURE INDEX | ASTM-D2863 | 250 C MINIMUM | TEMPERATURE INDEX | ASTM-D2863 | 250°C MINIMUM | |||
| TEMPERATURE INDEX | ASTM-D 2863 | 250 °C MINIMUM | ACID GAS GENERATION | IEC 60754-1 | 20% MAXIMUM | ACID GAS GENERATION | IEC 60754-1 | < 0.5% |
| SMOKE DENSITY RATING | ASTM-D2843 | 60% MAXIMUM | SMOKE DENSITY RATING | ASTM-D2843 | 60% MAXIMUM | |||
